F 75 L |
Flake Ice |
Technical parameters:
| Models |
Dimension [mm] H x W x D | Output [kg/day] | Storage Capacity [kg] | Weight [kg] |
|---|---|---|---|---|
| F 35 L | 637 x 345 x 520 | 40 | 10 | 39 |
| F 35 W | 637 x 345 x 520 | 40 | 10 | 39 |
| F 75 L | 850 x 485 x 590 | 80 | 25 | 55 |
| F 75 W | 850 x 485 x 590 | 80 | 25 | 55 |
| F 125 L | 1020 x 680 x 590 | 135 | 42 | 69 |
| F 125 W | 1020 x 680 x 590 | 135 | 42 | 69 |
| F 400 L | 1695 x 1020 x 780 | 460 | 220 | 180 |
| F 400 W | 1695 x 1020 x 780 | 460 | 220 | 180 |
Ice-making system: Evaporator cylinder with spiral conveyor
Cooling:
Description:
Available options:
Installation information: From a drinking water hardness of 12°dH or a conductivity of 350 μs/cm, the use of appropriately treated water is necessary.
Performance data of all models at ambient temperature of 15°C, water temperature of 10°C (air-cooled appliances) and condensing temperature of 20°C (water-cooled appliances). The capacity of the storage bins and dispensers in kg represents the complete utilization of the entire bin volume available.
