Combi Line

Ice Makers » Combi Line

W 80 ECL/ECW

W 80 ECL/ECW


W 120 ECL/ECW

W 120 ECL/ECW

W120 EL/CL

W120 EL/CL

Hollow Ice Cone

Hollow Ice Cone

Technical parameters:

Models

Dimension [mm]

H x W x D

Output [kg/day]Storage Capacity [kg]Weight [kg]
W 80 EL 1777 x 715 x 600 80 67 123
W 80 EW 1777 x 715 x 600 80 67 123
W 80 CL 1777 x 715 x 600 80 67 130
W 80 CW 1777 x 715 x 600 80 67 130
W 80 ECL 1777 x 715 x 600 80 67 138
W 80 ECW 1777 x 715 x 600 80 67 138
W 120 EL 1400 x 890 x 670 126 130 119
W 120 EW 1400 x 890 x 670 126 130 119
W 120 CL 1720 x 890 x 670 126 130 157
W 120 CW 1720 x 890 x 670 126 130 157
W 120 ECL 1720 x 890 x 670 126 130 162
W 120 ECW 1720 x 890 x 670 126 130 162
W 240 EL 1520 x 1020 x 890 240 220 190
W 240 EW 1520 x 1020 x 890 240 220 190
W 240 CL 1920 x 1020 x 890 240 220 235
W 240 CW 1920 x 1020 x 890 240 220 235
W 240 ECL 1920 x 1020 x 890 240 220 240
W 240 ECW 1920 x 1020 x 890 240 220 240

Ice-making system: Wave technology

Model designations / types of ice:

  • EL, EW = ice cones
  • CL, CW = crushed ice
  • ECL, ECW = ice cones  + crushed ice



Cooling:

  • EL,CL,ECL = air-cooled
  • EW,CW,ECW = water-cooled



Description:

  • stainless steel housing
  • power supply 230V / 50Hz
  • recommended ambient temperature for air cooled units +10 to +30°C
  • recommended ambient temperature for water cooled units +10 to +45°C
  • 1 year full warranty service and after warranty service provided



Available options:

  • All EL, CL, ECL machines can be prepared for attachment to a remote condenser.





Performance data of all models at ambient temperature of 15°C, water temperature of 10°C (air-cooled appliances) and condensing temperature of 20°C (water-cooled appliances). The capacity of the storage bins and dispensers in kg represents the complete utilization of the entire bin volume available.
